CGPS gripper, size 25 mm - dimensions
Mod.
Closing gripping force
each jaw at 6 bar (N)
Opening gripping force
each jaw at 6 bar (N)
Stroke per
jaw (mm)
Air consumption
per cycle (Ncm³)
Working
pressure (bar)
Working
temperature (°C)
Repeatability
(mm)
Max use
frequency (Hz)
Weight
(Kg)
CGPS-L-25
125
137
7
44.9
2 ÷ 8
5 ÷ 60
+/- 0.02
3
0.447
CGPS-F-25
125
137
7
44.9
2 ÷ 8
5 ÷ 60
+/- 0.02
3
0.464
CGPS-L-25-NC
143.2
111
7
24.1
4 ÷ 8
5 ÷ 60
+/- 0.02
3
0.456
CGPS-F-25-NC
143.2
111
7
24.1
4 ÷ 8
5 ÷ 60
+/- 0.02
3
0.471
CGPS-L-25-NO
100
152
7
20.9
4 ÷ 8
5 ÷ 60
+/- 0.02
3
0.456
CGPS-F-25-NO
100
152
7
20.9
4 ÷ 8
5 ÷ 60
+/- 0.02
3
0.471
DRAWING LEGEND:
A = Opening of air connection
B = Closing of air connection
C = Closed gripper
D = Open gripper
