CONTROL
Products designed for industrial applications.
General terms and conditions for sale are available on
CONTROL > Series SCU, MCU, SVU, MVU, SCO and MCO
CODING EXAMPLE
M ACTUATION:
M = Manual
S = Screwdriver
CU ASSEMBLY / VALVE TYPE:
CU = directly on double-acting cylinders / unidirectional
VU = directly on valves / unidirectional
CO = directly on valves exhaust / bidirectional
7 VERSIONS:
6 = needle (screwdriver operated)
7 = needle (manual operated)
02 NOMINAL DIAMETER:
02 = ø 1,5 max
04 = ø 2 max
06 = ø 4 max
08 = ø 7 max
10 = ø 12 max
M5 PORTS:
M5 = M5
1/8 = G1/8
1/4 = G1/4
3/8 = G3/8
1/2 = G1/2
M CU 7 02 - M5
Mod. MVU 710-1/2
Mod. SCO 610-1/2 Mod. MCO 710-1/2
Mod. SVU 610-1/2
Mod. SCO 602-M5+2905 M5
SCO 604-1/8+2905 1/8
SCO 606-1/4+2905 1/4
Silenced exhaust controllers
Mod. SCO + 2905
The flow control valve Mod. SCO and the silencer Mod. 2905
are supplied separately
Series RSW
Ports G1/8, G1/4 and G1/2
Mod. RSW 1/8
RSW 1/4
RSW 3/8
RSW 1/2
