NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
xvi
Product Guide
Guides
Series 45
page 58
For cylinders DIN/ISO 6432 - ø12, 16, 20, 25
For cylinders DIN/ISO 6431 - ø32, 40, 50, 63, 80, 100
Tie-rod Cylinders, ISO 6431,
ISO 15552 compliant
Series 60
page 13
Single or double-acting, magnetic, cushioned
Standard, low temperature and low friction versions
ø 32, 40, 50, 63, 80, 100, 125 mm
Extruded Body Cylinders,
ISO 6431, ISO 15552 compliant
Series 62
page 42
Double-acting, magnetic, cushioned
ø 32, 40, 50, 63, 80, 100, (ISO 15552)
Extruded Body Cylinders,
ISO 6431, ISO 15552 compliant
Series 61
page 28
Single or double-acting, magnetic, cushioned
Standard, low temperature and low friction versions
ø 32, 40, 50, 63, 80, 100, 125 mm
Rod Lock
Series RL
page 54
For cylinders ISO 6431/VDMA and ISO 6432
ø 20 - 25 - 32 - 40 - 50 - 63 - 80 - 100 - 125
Round Body Minicylinders, DIN/ISO 6432
Series 16, 24 and 25
page 4
Series 16: ø 8 - 10 - 12
Series 24: ø 16 - 20 - 25 magnetic
Series 25: ø 16 - 20 - 25 magnetic cushioned
EXPRESS DELIVERY AVAILABLE
EXPRESS DELIVERY AVAILABLE
EXPRESS DELIVERY AVAILABLE
