1089 / 1280
Prodotti destinati all’industria.
Condizioni generali di vendita disponibili sul sito
www.camozzi.com.
4
Raccordi super-rapidi Serie 6000
COLLEGAMENTO >
CATALOGO
>
Release 8.8
/1.05.03
4
COLLEGAMENTO
Raccordi Mod. 6512 Micro
DIMENSIONI
Mod.
A
D
F
H
L
SW1 Peso (g)
6512 3-M3
3
M3
5.8
2.5 10.2
1.5
1
⋆
6512 3-M5
3
M5
5.8
3.5
10
2
1
●
6512 4-M7-M 4
M7
9.4
5
17.5
2.5
5
●
6512 4-1/8-M 4
G1/8
11.2
5
13
2.5
9
●, Y
6512 6-M7-M 6
M7
10.4
5
17
4
7
●
6512 6-1/8-M 6
G1/8
11.2
5
14
4
7
●, Y
6512 8-1/8-M 8
G1/8
12.4
5
18.5
5
10
●, Y
6512 10-1/4-M 10
G1/4
14.8
6
21
7
16
●
Diritto Maschio Metrico-Cilindrico
⋆ = con guarnizione
● = con O-Ring
Raccordi Mod. 6512
DIMENSIONI
Mod.
A D C F
G H L SW SW1 Peso (g)
6512 4-M5 4 M5
6
7.8 8.8 4
20
8
2
4
6512 4-M6 4 M6 6.5 8.8 9.9 4.5 20.5 9
2.5
6
6512 4-1/8 4 G1/8 5
8.8 13.5 6
19 12 2.5
10
6512 4-1/4 4 G1/4 6.5 8.8 16.4 7 20.5 15 2.5
14
6512 5-M5 5 M5
6
8.8 9.9 4
21
9
2
5
6512 6-M5 6 M5
6 11.7 13.2 4
22 12
2
8
6512 6-M6 6 M6
6 11.7 13.2 4.5 22.5 12 2.5
8
6512 6-1/8 6 G1/8 5 11.7 13.5 6
21 12
4
10
6512 6-1/4 6 G1/4 6 11.7 16.4 7
22 15
4
13
6512 8-1/8 8 G1/8 8.5 13.7 15.2 6
26 14
5
15
6512 8-1/4 8 G1/4 7 13.7 16.4 7 24.5 15
6
17
6512 8-3/8 8 G3/8 6.5 13.7 20.5 7
23 19
6
27
6512 10-1/4 10 G1/4 9.8 15.4 18.5 7
30 17
7
26
6512 10-3/8 10 G3/8 5.3 15.4 20.5 7 24.5 19
8
27
6512 12-1/4 12 G1/4 10.5 18.3 20.5 7 29.5 19
7
29
6512 12-3/8 12 G3/8 5.8 18.3 20.5 7
24 19
9
24
Diritto Maschio Metrico-Cilindrico
Nuovo modello
