CONNECTION > Series 1000
Mod.
1410 5/3-1/8
1410 6/4-1/8
1410 6/4-1/4
1410 8/6-1/8
1410 8/6-1/4
1410 10/8-1/8
1410 10/8-1/4
1410 10/8-1/2
1410 12/10-3/8
1410 12/10-1/2
1410 15/12,5-1/2
Mod.
1420 5/3-1/8
1420 6/4-1/8
1420 6/4-1/4
1420 8/6-1/8
1420 8/6-1/4
1420 10/8-1/8
1420 10/8-1/4
Mod.
1521 5/3-M5
1521 5/3-1/8
1521 6/4-M5
1521 6/4-1/8
1521 6/4-1/4
1521 6/4-3/8
1521 8/6-1/8
1521 8/6-1/4
1521 8/6-3/8
BSPT Fix Male Tee Lateral BSPT Male Tee
Complete Metric-BSP
Single Adjustable Banjo
Mod.
1525 6/4-1/8
1525 6/4-1/4
1525 6/4-3/8
1525 8/6-1/8
1525 8/6-1/4
1525 8/6-3/8
1525 10/8-1/8
1525 10/8-1/4
1525 10/8-3/8
1525 10/8-1/2
1525 12/10-3/8
1525 12/10-1/2
1525 15/12,5-1/2
Mod.
1610 5/3-M5 •
1610 5/3-M6°
1610 5/3-1/8*
1610 6/4-M5 •
1610 6/4-M6°
1610 6/4-1/8*
1610 6/4-1/4*
1610 6/4-3/8*
1610 8/6-1/8*
1610 8/6-1/4*
1610 8/6-3/8*
1610 10/8-1/8**
1610 10/8-1/4**
1610 10/8-3/8**
1610 10/8-1/2^
1610 12/10-3/8**
1610 12/10-1/2^
1610 15/12,5-1/2^
Mod.
1620 6/4-M5°
1620 6/4-1/8*
1620 6/4-1/4*
1620 8/6-1/8*
1620 8/6-1/4*
Complete Single
Adjustable Long Banjo
Single Banjo
Assembled with:
• = Mod. 1631, 1635
° = Mod. SCU, SVU, SCO...
* = Mod. 1631, 1635,
SCU, SVU, SCO...
** =Mod. 1635, SCU, SVU,
SCO...
^ = Mod. 1635
Double Banjo
Assembled with:
° = Mod. 1631, 1635
* = Mod. 1631, 1635, SCU, SVU, SCO...
Mod.
1631 01-M5*
1631 01-1/8
1631 01-1/4
1631 01-3/8
1631 01-1/2
* = zinc-plated
steel
Mod.
1635 01-1/8
1635 01-1/4
1635 01-3/8
1635 01-1/2
1635 01-M12x1,25*
1635 01-M12x1,5*
Mod.
1631 02-1/8
1631 02-1/4
1631 02-3/8
Single Banjo Stem
Assembled with adjustable fittings
Mod. 6610, 6620, 1610, 1620, 2023, 1170
Single Long Banjo Stem
Assembled with adjustable fittings
Mod. 6610, 6620, 1610, 1620, 2023, 1170
* = Models that can be assembled with
1/4 banjo fittings
Double Banjo Stem
Assembled with adjustable fittings
Mod. 6610, 6620, 1610, 1620, 2023, 1170
Mod.
1635 02-1/8
1635 02-1/4
1635 02-3/8
1635 02-1/2
Mod.
1631 03-1/8
1631 03-1/4
1631 03-3/8
Mod.
1580 5/3
1580 6/4
1580 8/6
1580 10/8
1580 12/10
1580 15/12,5
1580 8/6-6/4
1580 10/8-6/4
Double Long Banjo Stem
Assembled with adjustable fittings
Mod. 6610, 6620, 1610, 1620, 2023, 1170
Triple Banjo Stem
Assembled with adjustable fittings
