VACUUM
Filters
Page
Series
Inline vacuum filters
190
FVD
For use in vacuum systems with
minor to medium levels of dirt.
Direct mounting on the suction pad.
Series
Vacuum cup filters
190
FVT
Used as pre-filters and fine filters for air
with varying amounts of contamination,
for the protection of the vacuum generator.
Mounted as protection for the ejector.
Pressure / vacuum switches
See chapter 2
Ejectors based on Venturi principle
Page
Series VEB
Basic ejectors
185
Basic ejectors with no moving parts,
based on the Venturi principle.
Version “L” for porosive workpieces.
Version “H” for high vacuum value.
Series VEBL
Basic ejectors
185
Basic ejectors in technopolymer
without moving parts,
based on the Venturi principle.
Different sizes available, with internal
nozzle from 0,5 to 2,5 mm and with
suction rate from 8 to 207 l/min.
Series
Inline ejectors
186
VED
Vacuum ejectors without moving parts,
based on the Venturi principle,
used for direct installation on suction pads.
Series VEDL
Inline ejectors
186
Vacuum compact ejectors
in technopolymer without moving parts,
based on the Venturi principle,
used for direct installation on suction pads.
Available in two sizes with internal nozzle
of 0,5 and 0,7 mm and with suction rate
from 8 to 16 l/min.
Series
Compact ejectors
187
VEC
Vacuum generators with integrated valves
and monitoring system.
Possibility to command suction and blow-off
individually without using external valves.
Series
Compact ejectors
188
VEM
Miniaturized vacuum generators with
integrated valves and monitoring system.
Possibility to command suction and blow-off
individually without using external valves.
Accessories
Page
Series
Flexible suction pad
189
NPF
mountings
The vulcanisation provides flexibility
in all directions. Thread G1/4.
Series NPM, NPR Spring plungers
189
The spring plungers are used in situations
where significant height differences
of the workpiece have to be compensated for.
Thread size M3, M5, G1/8, G1/4,
plunger stroke length from 5 to 75 mm.
Series VNV
Check valves
189
These check valves are mainly used on
vacuum gripper systems containing multiple
suction pads in order to shut off individual
suction pads which are not covered.
Thread size M5, G1/8, G1/4, G3/8, G1/2.
