MOVEMENT > Pneumatic symbols for cylinders
Symbol Type
CDSS
Double-acting rodless cylinder,
magnetic
CS01
Single-acting cylinder,
front spring
CS02
Single-acting cylinder,
front spring
CS03
Single-acting cylinder,
non cushioned
CS04
Single-acting cylinder,
through-rod
CS05
Single-acting cylinder, through-rod,
adjustable cushion
CS06
Single-acting cylinder,
magnetic
CS07
Single-acting cylinder, front spring,
adjustable rear cushion
CS08
Single-acting cylinder, rear spring,
magnetic
CS09
Single-acting cylinder, magnetic,
front spring
CS10
Single-acting cylinder, through-rod
CS11
Single-acting cylinder, through-rod,
adjustable rear cushion
CS12
Single-acting cylinder, front spring,
adjustable rear cushion
CS13
Single-acting cylinder, through-rod,
adjustable rear cushion
Symbol Type
CS14
Single-acting, rear spring
HI01
Hydrocheck, regulated rod thrust
HI02
Hydrocheck, regulated rod return
HI03
Hydrocheck, regulated rod thrust
with stop valve
HI04
Hydrocheck, regulated rod return
with stop valve
HI05
Hydrocheck, regulated rod thrust
with skip valve
HI06
Hydrocheck, regulated rod return
with skip valve
HI07
Hydrocheck, regulated rod thrust
with skip and stop valve
HI08
Hydrocheck, regulated rod return
with skip and stop valve
PNZ1
Double-acting magnetic gripper
PNZ2
Single-acting, NC, magnetic gripper
PNZ3
Single-acting, NO, magnetic gripper
RDLK
Rod lock device
