SHORT FORM CATALOGUE > Release 8.8
2
CONTROL
Products designed for industrial applications.
General terms and conditions for sale are available on
CONTROL > Series A
A SERIES
3 BODY DESIGN:
1 = base ( 24x24 mm ) interface rotatable through 360°
2 = base ( 24x24 mm ) fixed interface
3 = threaded body
4 = rapid exhaust body
5 = base with ISO standard interface, fixed body in technopolymer
6 = ( 16x16 mm ) interface rotatable through 360°
A = single manifold
B = 2-part manifold
C = 3-part manifold
D = 4-part manifold
E = 5-part manifold
F = 6-part manifold
G = 7-part manifold
H = 8-part manifold
K = 9-part manifold
L = 10-part manifold
M = 11-part manifold
N = 12-part manifold
P = 13-part manifold
R = 14-part manifold
S = 15-part manifold
3 NUMBER OF PORTS:
2 = 2 way
3 = 3 way
1 FUNCTION:
1 = NC
2 = NO
3 = NO in line
0 PORTS:
1 2 3
0 M5 M5 M5
1 G1/8 G1/8 M5
3 M5 G1/8 male M5
4 M5 G1/8 male M5 with manual override
A swivel O-ring interface M5
B fixed O-ring interface M5
C cartridge ø 4
C NOMINAL DIAMETER:
C = ø 1,5
D = ø 2
E = ø 2,5
2 BODY MATERIAL:
2 = nickel-plated brass
3 = technopolymer
U ENCAPSULATING MATERIAL / SOLENOID DIMENSIONS:
A8 = PPS / 30x30
G7 = PA / 22x22
G8 = PA / 30x30 (24 V DC only)
G9 = PA / 22x58
H8 = PA 6 V0 / 30x30
U7 = PET / 22x22
7 SOLENOID VOLTAGE:
U7** G7** A8** H8** G9**
B 24V AC 50/60Hz - - 5VA 5,3VA -
C 48V AC 50/60Hz - - - 5,3VA -
D 110V AC 50/60Hz - - 5VA 5,3VA -
E 230V AC 50/60Hz - - 5VA 5,3VA -
F 380V AC 50/60Hz 7VA 7VA - - -
H 24V 50/60Hz 3,5VA 3,5VA - - -
12V DC 3,1W 3,1W - - -
K 72V DC 4,8W 4,8W - - -
110V AC 50/60Hz 3,8VA 3,8VA - - -
125V AC 50/60Hz 5,5VA 5,5VA - - -
K1* 72V DC 5,6W 5,6W - - -
110V AC 50/60Hz 5,8VA 5,8VA - - -
125V AC 50/60Hz 8,3VA 8,3VA - - -
J 230V AC 50/60Hz 3,5VA 3,5VA - - -
240V AC 50/60Hz 4VA 4VA - - -
1 6V DC 5,1W 5,1W - - -
2 12V DC 5W 5W - - -
3 24V DC 5W 5W 4W 5,4W 4/2W
4 48V DC 5,3W 5,3W 4W - -
6 110V DC 4,2W 4,2W - - -
7 24V DC 3,1W 3,1W - - -
48V AC 50/60 Hz 3,5VA 3,5VA - - -
71* 24V DC 3,1W 3,1W - - -
48V AC 50/60Hz 3,5VA 3,5VA - - -
9 48V DC 3,1W 3,1W - - -
10 110V DC 3,2W 3,2W - - -
* = only for valves NO in-line
** = substitute 0 with letter or number at the beginning of the line
CODING EXAMPLE
A 3 3 1 - 0 C 2 - U7 7
