Modell- und Maßänderungen vorbehalten.

Unsere AGBs finden Sie auf

www.camozzi.de

.

Soft-Startventil Serie MX

KATALOG

3

/1.40.02

3

>

Version 8.8

AUFBEREITEN >

AUFBEREITEN

MODELLBEZEICHNUNG

MX

SERIE

2

GRÖSSE:

2 = G3/8 - G1/2 - G3/4

3 = G3/4 - G1

3/8

ANSCHLUSS:

3/8 = G3/8

1/2 = G1/2

3/4 = G3/4

1 = G1

AV

SOFT-STARTVENTIL

LH

DURCHFLUSSRICHTUNG:

= von links nach rechts(Standard)

LH = von rechts nach links

Weitere Details zur Leitungs-, Wandmontage direkt oder mit Abstandshalter siehe Wartungseinheiten Serie MX (Seite 3/1.50.01).Zubehör siehe ab 3/5.07.01.

MX 2

-

3/8

-

AV

-

LH

WERKSTOFFE

TEILE

WERKSTOFFE

1 = Körper

Aluminium

2 = Abdeckung

Polyacetal

3 = Ventilträger-Verschlussplatte

Polyacetal

4 = Untere Feder

Edelstahl

Dichtungen

NBR

Soft-Startventile Serie MX - Werkstoffe
