Series VNRC unidirectional valves
Cartridge construction for mounting in manifold
This valve allows the passage of the fluid
from the inlet to the outlet preventing
preventing any flow in the opposite
direction.
The valve ensures a low minimum
opening pressure and a high flow of the
gaseous fluid.
» » Compact design
»
» High performance
» » Ease of installation
» » Compatibility between
materials used and
several gaseous fluids
»
» Suitable for applications
with oxygen
GENERAL DATA
TECHNICAL FEATURES
Construction
Pneumatic connections
Nominal diameter
Working pressure
Minimum operating pressure
Working pressure
Medium
Installation
guided tightening element
cartridge in manifold
4 mm
0 ÷ 10 bar
0.05 bar
-5 ÷ 50°C
air, inert/medical gases and oxygen
any position
MATERIALS IN CONTACT WITH THE MEDIUM
Body
Seals
Stainless steel
EPDM
New
