Products

Vacuum and pressure switches

Our range of vacuum and pressure switches includes compact and light solutions, able to satisfy the most different conditions of application

and use. The electronic pressure switches with digital display are ideal for safety monitoring and enable the optimization of cycle times or

energy saving devices. Thanks to the programmable switching point and hysteresis, they perfectly suit the customer’s needs.

The two separate outputs (digital and analog) are programmable and enable the setting of upper and lower limit vacuum values and

continuous vacuum control.

Series MD modular FRL units

The Series MD air preparation product line is characterized by a modern and linear design as well as high performance.

The technopolymer structure has allowed to create a simplified, product, lightweight and robust at the same time.

Series SWDN electronic vacuum/pressure switches

2/8.22 *

» With digital display

» High precision, easy to use

» Digital indicator: precision electronic insertion with

two separated switch outputs

» Switching point and hysteresis can be programmed

with a membrane keypad

» Port: with external thread G1/8 and internal thread M5

» Electric connection: with M8 4-pole connector or pre-wired

cable of 2 meters

Series SWCN electronic vacuum/pressure switches

» With digital display

» High precision, easy to use

» Digital indicator: precision electronic insertion

with two separated switch outputs

» Switching point and hysteresis can be programmed

with a membrane keypad

» Upper and lower limit values can be programmed

through two PNP switch outputs

» Port: with external thread G1/8 and internal thread M5

» Electric connection: with M8 4-pole connector or pre-wired

cable of 2 meters

2/8.27 *

The complete catalogue of our Series MD Modular FRL Units is available on the site

http://catalogue.camozzi.com

*Section of reference inside the Camozzi catalogue

The complete catalogue of our vacuum and pressure switches is available on the site

http://catalogue.camozzi.com

*Section of reference inside the Camozzi catalogue

Filters, coalescing filters, activated carbon filters, regulators and take-off blocks

3 / 1 *

Filters:

» Removal of impurities and condensate

» Visual blockage indicator

» Condensate drain options: semi-automatic manual,

automatic protected depressurisation, direct G1/8 exhaust

» Bowl locking system reducing the risk of accidents

» Additional air intakes with the same characteristics

of the outlet air (line)

Coalescing filters:

» High performance and high purity compressed air

» Air quality according to ISO 8573-1:2010 standard,

Class 1.8.1 and Class 2.8.2

Activated carbon filters:

» Removal of oil, liquid and gaseous components from

compressed air through the active carbons

» Air quality in compliance with ISO 8573-1 standard, Class 1.7.1

Regulators:

» Minimal pressure decreases

» Knob with position lock

» Tamper-proof system (lockable regulator)

» With or without overpressure exhaust (relieving)

Take-off blocks:

» Compact design

» Utilities orientation
