Products
Fittings
Our range of fittings and accessories is composed of numerous series in brass and technopolymer studied in order to respond to the
needs of different types of systems. Super-rapid, rapid, universal fittings, accessories and couplings are available in different sizes with
threads ranging from M3 to G1. The patented Sprint
®
system guarantees tightening even under the worst conditions, with the possibility
to repeat the connection and disconnection of the fitting several times.
The complete catalogue of our fittings is available on the site
http://catalogue.camozzi.com.
*Section of reference inside the Camozzi catalogue
Series 6000 super-rapid fittings for plastic tubes
Series 8000 dual seal super-rapid fittings
4/1.05 *
4 / 1.15 *
Series 7000 super-rapid Compact fittings
4/1.10 *
Series 1000 rapid push-in fittings for plastic tubes
Series 5000 quick-release couplings
4 / 2.05 *
4 / 5.05 *
Series X6000 super-rapid fittings
Series 2000 pipe fittings
4 / 1.25 *
4 / 4.10 *
» In nickel-plated brass
» Tube external diameters: 3, 4, 5, 6, 8, 10, 12, 14, 16mm
» Fittings threads: M3, M5, M6, M7, G1/8, G1/4, G3/8, G1/2,
G3/4, R1/8, R1/4, R3/8, R1/2
» In nickel-plated brass
» Tube external diameters: 4, 6, 8, 10, 12mm
» Fittings threads: G1/8, G1/4, G3/8, G1/2
» In stainless steel 316L
» Tube external diameters: 4, 6, 8, 10, 12mm
» Fittings threads: G1/8, G1/4, G3/8, G1/2, R1/8, R1/4,
R3/8, R1/2
» In nickel-plated brass
» Fittings threads: M5, G1/8, G1/4, G3/8, G1/2, G3/4, G1,
R1/8, R1/4, R3/8, R1/2, R3/4, R1
» In technopolymer
» Tube external diameters: 4, 6, 8, 10, 12, 16mm
» Fittings threads: M5, M7, G1/8, G1/4, G3/8, G1/2, G3/4
» In nickel-plated brass
» Diameters: 4, 6, 8, 10, 12, 14, 16mm
» Fittings threads: Gas cylindrical ISO-228 (BSP)
» In nickel-plated brass
» Tube external diameters: 5/3, 6/4, 8/6, 10/8, 12/10, 15/12.5mm
» Fittings threads: M5, M6, M12 x1, M12 x1.25, G1/8, G1/4,
G3/8, G1/2, R1/8, R1/4, R3/8, R1/2
» In nickel-plated brass
» Nominal diameters: 5.7mm
» Threads: G1/8, G1/4, G3/8, G1/2
a
/1
03
Series H8000 fittings with double tightening
for harsh environments
