SHORT FORM CATALOGUE > Release 8.8
2
CONTROL
Products designed for industrial applications.
General terms and conditions for sale are available on
CONTROL > Series 9
Accessories
Single sub-base with rear outlets
(VDMA 24345)
Mod. 901-G1A
902-G2A
903-G3A
Single sub-base side outlets
(VDMA 24345)
Mod. 901-F1A
902-F2A
903-F3A
End block for manifold sub-base
(VDMA 24345)
The following is supplied:
2x end blocks (1 pair),
2x fixing screws,
3x OR
Mod. 901-H1
902-H2
903-H3
Manifold sub-base with com. exhausts and inlet
(VDMA 24345)
The following is supplied:
2x fixing screws,
3x O-ring
Mod. 901-C1A
902-C2A
903-C3A
Manifold bases with common inlet
and exhaust ports and front outlet
The following is supplied:
2x fixing screws,
3x OR
Mod. 901-N1A
Interface with front outlets
(VDMA 24345)
The following is supplied:
2x fixing screws,
2x OR
Mod. 901-N1
902-N2
903-N3
End blocks for manifold bases
with front outlets
The following is supplied:
2x end blocks (1 pair),
2x fixing screws,
3x OR
Mod. 901-HN1
Mounting example
Separation tap lines 1 - 3 - 5
to be used with manifold
type 901C and 902C
Mod. 901-C1A/TP
902-C2A/TP
Separation joint
To be used with manifold type 901N
P plugged
Mod. 901-N1A/TP
Separation joint
To be used with manifold type 901N
P-R-S plugged
Mod. 901-N1A/T
