ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
94
Switches Series CSN
For cylinders Series 40 from ø 160 – 250 (mounting band Mod. S21 to be ordered separately).
For cylinders Series 41 from ø 160 - 200 (mounting band Mod. S53 to be ordered separately).
For cylinders Series 60 from diam 32mm - 100mm bore, direct mounting on tie-rods.
Mod.
CSN 2032-0
Mounting bracket for sensor
Mod.
S21
for cylinders Series 40 ø 160 - 200 and 250
S53
for cylinders Series 41 ø 160 and 200
Tie-Rod diam 6 - 10mm
