Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
101
2
Compact & Short-Stroke Cylinders
Page
Series 14
Threaded Body Minicylinders
102
Series 31
Compact Cylinders
105
Series 31
Compact Cylinders
Tandem and Multi-Position Versions
120
Series 32
Compact Cylinders, ISO 21287 compliant
124
Series 32
Compact Cylinders ISO 21287 compliant
Tandem and Multi-Position Versions
141
Series QN
Short-Stroke Cylinders
145
Series QP
and QPR
Short-Stroke Cylinders
148
Series 27
Round Body Cylinders
158
Series 42
Round Body Cylinders
166
Table showing the compatibility of magnetic proximity
switches by cylinder series
174
