SEAL KITS & TECHNICAL DATA
Seal Kits & Technical Data
8
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
354
COMPACT CYLINDERS
Buna Kit (NBR)
Viton Kit
QN1A08
NON REPAIRABLE
QN1A12
K02-Q12
K02V-Q12
QN1A20
K02-Q20
K02V-Q20
QN1A32
K02-Q32
K02V-Q32
QN1A50
K02-Q50
K02V-Q50
QN1A63
K02-Q63
K02V-Q63
QP & QPR2A12
K02-QP12
K02V-QP12
QP & QPR2A16
K02-QP16
K02V-QP16
QP & QPR2A20
K02-QP20
K02V-QP20
QP & QPR2A25
K02-QP25
K02V-QP25
QP & QPR2A32
K02-QP32
K02V-QP32
QP & QPR2A40
K02-QP40
K02V-QP40
QP & QPR2A50
K02-QP50
K02V-QP50
QP & QPR2A63
K02-QP63
K02V-QP63
QP & QPR2A80
K02-QP80
K02V-QP80
QP & QPR2A100
K02-QP100
K02V-QP100
31
M,F,R2A12
K02-31-12
N/A
31
M,F,R2A16
K02-31-16
N/A
31
M,F,R2A20
K02-31-20
N/A
31
M,F,R2A25
K02-31-25
N/A
31
M,F,R2A32
K02-31-32
N/A
31
M,F,R2A40
K02-31-40
N/A
31
M,F,R2A50
K02-31-50
N/A
31
M,F,R2A63
K02-31-63
N/A
31
M,F,R2A80
K02-31-80
N/A
31
M,F,R2A100
K02-31-100
N/A
GRIPPERS
Buna Kit (NBR)
CGA-10-1
K02-CGA-10
CGA-16-1
K02-CGA-16
CGA-20-1
K02-CGA-20
CGA-25-1
K02-CGA-25
CGA-32-1
K02-CGA-32
CGS-16
K02-CGS-16
CGS-20
K02-CGS-20
CGS-25
K02-CGS-25
CGS-32
K02-CGS-32
CGP-10
K02-CGP-10
CGP-16
K02-CGP-16
CGP-20
K02-CGP-20
CGP-25
K02-CGP-25
CGP-32
K02-CGP-32
CGB-L,S-16
K02-CGB-16
CGB-L,S-20
K02-CGB-20
CGB-L,S-25
K02-CGB-25
CGB-L,S-32
K02-CGB-32
CGL-10-00
K02-CGL-10
CGL-16-00
K02-CGL-16
CGL-20-00
K02-CGL-20
CGL-25-00
K02-CGL-25
CGL-32-00
K02-CGL-32
CGC-050-00
K02-CGC-050
CGC-064-00
K02-CGC-064
CGC-080-00
K02-CGC-080
CGC-100-00
K02-CGC-100
CGC-125-00
K02-CGC-125
KITS:
All the parts (pre-assembled) of a complete cylinder without
tube, rod and tie-rods, NBR seals.
KITSV:
All the parts (pre-assembled) of a complete cylinder
without tube, rod and tie-rods, VITON seals.
K02:
All cylinders’ soft seals in NBR (Rod wiper seal, tube end
seals, piston seals, cusion adjustment screw seals, wear band,
bumpers).
K02V:
All cylinders’ soft seals in VITON (Rod wiper seal, tube end
seals, piston seals, cusion adjustment screw seals, wear band,
bumpers).
K03:
All cylidners’ soft seals in NBR for single acting cylinders
(
Rod wiper seal, tube end seals, piston seals, cusion adjustment
screw seals, wear band, bumpers).
K03V:
All cylidners’ soft seals in VITON for single acting cylinders
(
Rod wiper seal, tube end seals, piston seals, cusion adjustment
screw seals, wear band, bumpers).
K04:
All cylinders’ soft seals in NBR for single acting cylinders
(
Rod wiper seal, tube end seals, piston seals, cushion adjustment
screw seals, wear band, bumpers).
K04V:
All cylinders’ soft seals in VITON for single acting cylinders
(
Rod wiper seal, tube end seals, piston seals, cushion adjustment
screw seals, wear band, bumpers).
K2, K2V, K3, K3V, K4, K4V:
As above but complete with piston.
Spare Parts & Seal Kits
Cylinder Repair Kits Legend
