Fittings Mod. S2520...
Fittings Mod. 2520...
Fittings Mod. 2521...
DIMENSIONS
Mod.
A
B
H
L
SW
S2520 1/8-1/8
R1/8 G1/8 7.5
17.5
13
S2520 1/8-1/4
R1/8 G1/4 7.5
19
17
S2520 1/8-3/8
R1/8 G3/8 7.5
20
20
S2520 1/4-1/4
R1/4 G1/4 11
22.5
17
S2520 1/4-3/8
R1/4 G3/8 11
23.5
20
S2520 1/4-1/2
R1/4 G1/2 11
27.5
24
S2520 3/8-3/8
R3/8 G3/8 11.5
24
20
S2520 3/8-1/2
R3/8 G1/2 11.5
28
24
S2520 1/2-1/2
R1/2 G1/2 14
30.5
24
DIMENSIONS
Mod.
A
B
H
L
SW
2520 1/8-1/8
R1/8 G1/8 7.5
17.5
13
2520 1/8-1/4
R1/8 G1/4 7.5
19
17
2520 1/8-3/8
R1/8 G3/8 7.5
20
20
2520 1/4-1/4
R1/4 G1/4 11
22.5
17
2520 1/4-3/8
R1/4 G3/8 11
23.5
20
2520 1/4-1/2
R1/4 G1/2 11
27.5
24
2520 3/8-3/8
R3/8 G3/8 11.5
24
20
2520 3/8-1/2
R3/8 G1/2 11.5
28
24
2520 1/2-1/2
R1/2 G1/2 14
30.5
24
DIMENSIONS
Mod.
A
B
H
L
SW
2521
M5-1/8
M5
1/8
4
14
13
2521 1/8-1/8
1/8 1/8
6
16
13
2521 1/8-1/4
1/8 1/4
6
17.5
17
2521 1/8-3/8
1/8 3/8
6
18.5
20
2521 1/4-1/4
1/4 1/4
8
19.5
17
2521 1/4-3/8
1/4 3/8
8
20.5
20
2521 1/4-1/2
1/4 1/2
8
24.5
24
2521 3/8-3/8
3/8 3/8
9
21.5
20
2521 3/8-1/2
3/8 1/2
9
25.5
24
2521 1/2-1/2
G1/2 G1/2 10
26.5
24
Sprint
®
Adapter
BSPP Female — BSPP Male Adapter
BSPP Female - BSPT Male Adapter
B S P / M E T R I C
The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
80
F I T T I N G S
2
n i c k e l - p l a t e d b r a s s p ip e F I T T I NGS
