ANSTEUERN

2

2

>

Ansteuern

2 / 7

Strom- und Sperrventile

Kapitel

Serie

Strom- und Sperrventile

2/7.05

SCU,

Hohlschraubenausführung

MCU,

Drossel-, Drosselrückschlag-Funktion

SVU,

Anschlüsse: M5, G1/8”, G1/4”, G3/8”, G1/2”

MVU,

SCO,

MCO

Serie

Strom- und Sperrventile

2/7.07

PSCU,

Strom- und Sperrventile mit Drossel-,

PMCU,

Drosselrückschlag-Funktion

PSVU,

Anschlüsse M5, G1/8”, G1/4”, G3/8”

PMVU,

Hohlschraubenausführung mit einstellbarem

PSCO,

Steckanschluss in Messing vernickelt (M5)

PMCO

oder in Kunststoff (G1/8”, G1/4”, G3/8”)

Serie

Strom- und Sperrventile

2/7.10

TMCU,

Drossel- und Drosselrückschlagventile

TMVU,

Anschlüsse G1/8”, G1/4”, G3/8”, G1/2”

TMCO

Hohlschraubenausführung

Nennweite ø 2 - 3,8 - 5,8 - 8 mm

Serie

Strom- und Sperrventile

2/7.15

GSCU,

Drossel-, Drosselrückschlagventile

GMCU,

Anschlüsse M5, G1/8” und G1/4”

GSVU,

Hohlschraubenausführung,

GMVU,

Steckanschluss ø 3, 6, 8, 10 mm

GSCO,

Nennweite ø 1,5 - 3,5 - 5 mm

GMCO

Serie

Strom- und Sperrventile

2/7.20

RFU,

Drosselrückschlagventile RFU,

RFO

Drosselventile RFO

Anschlüsse: M5, G1/8”, G1/4”, G3/8”, G1/2”

Nennweiten: M5 ø 1,5 mm; G1/8” ø 2 und 3 mm

G1/4” ø 4 und 6 mm; G3/8” und G1/2” ø 7 mm

Serie

Stromventile

2/7.25

28

Drosselventile NW 4 - 5 - 7,5 - 9 mm

Anschlüsse: G1/8”, G1/4”, G3/8”, G1/2”

2 / 4

Wegeventile mechanisch und manuell betätigt

Kapitel

Serie

Miniventile mechanisch

2/4.05

2

betätigt

3/2-Wege

Anschluss M5, Steckanschluss ø 4 mm

Serie

Miniventile mechanisch

2/4.10

1, 3

betätigt

3/2-, 5/2-Wege, Anschlüsse G1/8” und G1/4”

Nennweite 5 - 7,5 mm

Serie

Wegeventile sensibel,

2/4.15

3, 4

mechanisch betätigt

3/2-, 5/2-Wege

Anschlüsse G1/8” und G1/4”

Serie

Fußventil, pneumatisch

2/4.20

2, 3

und elektrisch

Serie 3: G1/4” und 5/2-Wege

elektrischer Kontakt NC/NO

Serie 2: M5, Steckanschluss ø 4 mm, 3/2-Wege NC

Serie

Miniventile manuell

2/4.25

2

betätigt

3/2-, 5/3-Wege, Mitte entlüftet, Schalttafeleinbau

Anschlüsse M5, Steckanschluss ø 4 mm,

Serie

Manuell betätigte

2/4.30

1, 3, 4

Wegeventile

VMS

Serie 1, 3, 4: 3/2-, 5/2-, 5/3-Wege CC, CO

Anschlüsse: G1/8 und G1/4

Serie VMS: 3/2-Wege

Anschlüsse: M5, G1/8, G1/4, G3/8, G1/2, G3/4

Serie

Handgriff

2/4.35

2

mit 3/2-Wegeventil

Handgriff mit pneumatischem Miniventil 3/2-Wege,

NC und NO

Handgriff mit Mikroschalter, integriert

2 / 5

Logikventile

Kapitel

Serie 2L

Logikelemente

2/5.05

Steckanschluss ø 4 mm

ODER - UND - IDENTITÄT - NICHT - SPEICHER

2 / 6

Sperrventile, Schnellentlüftungsventile

Kapitel

Mod.

Wechselventile

2/6.01

SCS

Anschlüsse: G1/8"

Serie

Rückschlagventile

2/6.02

VNR

Anschlüsse: M5, G1/8”, G1/4”, G3/8”,

G1/2”, G3/4”, G1”

Serie

Schnellentlüftungsventile

2/6.03

VSO,

Anschlüsse Serie VSO: M5, G1/8”,

VSC

Steckanschluss ø 4 mm

Anschlüsse Serie VSC: G1/8”, G1/4”, G1/2”

Mod.

Ventil mit regulierbarer

2/6.04

VMR

Entlüftung

1/8-B10

Anschlüsse: G1/8"

Seri

Stopventil und

2/6.10

VBO,

entsperrbares Rückschlagventil

VBU

Anschlüsse: G1/8”, G1/4”, G3/8” und G1/2”
