APPENDIX
APPENDIX >
Info
Solenoids
Series
Category
Zone
Gas/Dust
U70
3
2/22
G/D
U80
2
1/21
G/D
U80I**
2
1/21
G/D
Pressure switches
Series
Category
Zone
Gas/Dust
PM 11**
1
0/20
G/D
FRL
Series
Category
Zone
Gas/Dust
MC#
2
1/21
G/D
N
2
1/21
G/D
MX#
2
1/21
G/D
T
2
1/21
G/D
CLR
2
1/21
G/D
M
2
1/21
G/D
Products
Category
Zone
Gas/Dust
Silencers
2
1/21
G/D
Quick release couplings 2
1/21
G/D
Manifolds
2
1/21
G/D
Subbases
2
1/21
G/D
Feet
2
1/21
G/D
Caps
2
1/21
G/D
Plates
2
1/21
G/D
Valvole
Series
Category
Zone
Gas/Dust
9#*
2
1/21
G/D
K
3
2/22
G/D
P
3
2/22
G/D
W
3
2/22
G/D
A#
2
1/21
G/D
3#
2
1/21
G/D
4#
2
1/21
G/D
NAMUR#
2
1/21
G/D
E (pneumatic)
2
1/21
G/D
E (electropneumatic)
3
2/22
G/D
Y
3
2/22
G/D
2
2
1/21
G/D
* According ISO
** Products with ATEX and IECEX certification
# Without solenoid
ATEX CERTIFIED CAMOZZI PRODUCTS
»
The order code number of the certified products
is obtained by adding “EX” to the standard article number
Es. 358-015
standard solenoid valve
Es. 358-015EX ATEX certified solenoid valve
APPARATUS REGARDING ATEX - GROUP II
COMPONENTS regarding ATEX - Group II
Accessories available in category 2 zone 1/21: couplings, junctions, brackets, piston rod nuts, nuts, counter brackets, bushings, pins, clevis pins, caps,
gaskets, diaphragm, sub-bases, plates, feet, hand operated valves, flow valves, flanges, screw, tie rods, automatic and blocking valves, silencers and
pressure gauge, connector kits, clamps, rapid and super rapid push-in fittings, hoses, sealing rings, locking nuts. Accessories available in category 3, zone
2/22: adaptors, slot covers, extensions, connectors. For more informations on this kind of products see the website:
http://catalogue.camozzi.comwithin the section: Downloads > Certifications > ATEX Directive 2014/34/EU > List of products excluded from the directive 2014/34/EU ATEX.
a
/2
12
DEGREE OF PROTECTION
AGAINST THE PENETRATION OF
FOREIGN BODIES COMING INTO
CONTACT WITH LIVE PARTS
Not protected
Protected against
solid bodies
greater than Ø 50mm
Protected against
solid bodies
greater than Ø 12mm
Protected against
solid bodies
greater than Ø 2.5mm
Protected against
solid bodies
greater than Ø 1mm
Protected against
dust
Totally protected against
dust
DEGREE OF PROTECTION
AGAINST THE
PENETRATION OF LIQUIDS
IP 0
X
IP 1
X
IP 2
X
IP 3
X
IP 4
X
IP 5
X
IP 6
X
Not protected
IP
X
0 IP 00 IP 10 IP 20 IP 30 IP 40 IP 50 IP 60
Protected against
water falling vertically
(condensate)
IP
X
1
IP 11 IP 21 IP 31 IP 41
Protected against
drops of water falling
up to 15° off the vertical
IP
X
2
IP 12 IP 22 IP 32 IP 42
Protected against
rain water
up to 60° off the vertical
IP
X
3
IP 23 IP 33 IP 43
Protected against
sprays of water
from any direction
IP
X
4
IP 34 IP 44 IP 54
Protected against
jets of water
fired from any direction
IP
X
5
IP 55 IP 65
Protected against
sea waves or the like
IP
X
6
IP 66
Protected against
the effects of immersion
IP
X
7
IP 67
IP PROTECTION CLASS
IP 6 5
DEGREE OF PROTECTION
AGAINST THE PENETRATION
OF LIQUIDS
DEGREE OF PROTECTION AGAINST
THE PENETRATION OF FOREIGN
BODIES COMING INTO CONTACT
WITH LIVE PARTS
