C_FLUID CONTROL RANGE OF PRODUCTS
P
PD
PDV
PL
PN
A
6
8
8
VALVE
WIDTH
15mm
15mm
15mm
15mm
15mm
22mm
30mm
10 ... 22mm 16 ... 32mm
FUNCTION
3/2
NC - NO
2/2
NC
2/2
NC
3/2
NC
3/2
NC
2/2 - 3/2
NC - NO
2/2 - 3/2
NC - NO
2/2 - 3/2
NC - NO
2/2 - 3/2
NC - NO
OPERATION
poppet
poppet
membrane
poppet
poppet
poppet
poppet
spool
spool
PNEUMATIC
CONNECTIONS
flange
flange - M5
flange
flange
flange
M5 - 1/8
flange - 1/4
cartridge
1/8 - 3/8
NOMINAL
DIAMETER
0.8 ... 1.5mm 0.8 … 2.5mm 0.8 … 2mm 1.5mm
0.8mm
1.5 … 2.5mm 2 ... 4mm 5 ... 9mm 5 ... 9mm
FLOW
14 … 35 l/min 25 ... 125 l/min 0,3 ... 0,9 Kv
24 … 35 l/min 12 l/min
40 … 130 l/min 80 ... 520 l/min 420 ...1480 Nl/min 420 ...1480 Nl/min
OPERATING
PRESSURE
0 ÷ 3 … 10 bar -0.9 ÷ 4 … 12 bar -0.9 ÷ 0 …
0 ÷ 10 bar
-0.9 ÷ 3 … 8 bar 0 ÷ 10 bar
-0.9 … 15 bar 0 ÷ 6 … 15 bar -0.9 … 7 bar
3 ÷ 6 bar;
0 ÷ 6 bar
(ext, pilot)
OPERATING
TEMPERATURE
0° ÷ +50°C 0° ÷ +50°C 0° ÷ 50°C
0° ÷ +50°C 0° ÷ +50°C 0° ÷ +60°C 0° ÷ +80°C 0° ÷ 50°C
0° ÷ 50°C
MEDIA
inert gases
inert gases
and liquids
aggressive gases
and liquids
inert gases
inert gases
inert gases
and liquids
inert gases
and liquids
inert gases
inert gases
SEALS
FKM
NBR
NBR
EPDM
FKM
FFKM
FKM
NBR
PU
NBR
HNBR
NBR
NBR
FKM
FKM
VOLTAGE
24 … 110 V DC
24 … 110 V AC 24 … 110 V DC 6 - 12 - 24 V DC 24 V DC
24 … 205 V DC 12 … 110 V DC
24 … 380 V AC
12 … 110 V DC
24 … 230 V AC
6 - 12 - 24 V DC
POWER
CONSUMPTION
1 ... 2 W 1 ... 4 W
2 W
2.7 W
1 ... 2 W 3 … 5 W
3.5 … 7 VA
10 W
19/12 VA
1,3 ... 2 W
DUTY CYCLE ED 100% ED 50% … 100% ED 100% ED 100% ED 100% ED 100% ED 100%
ED 100%
ELECTRICAL
CONNECTION
DIN 43650,
(C Shape), 9.4mm
connector
DIN 43650
(C Shape), 9.4mm
connector
DIN 43680
(C Shape), 9.4mm
(C Shape), 8mm
connectors
DIN 43650,
(C Shape), 9.4mm
connector
DIN 43650
(C Shape), 9.4mm
connector
DIN 43650
(A, B Shape)
connector
DIN 43650
(A Shape)
connector
DIN 43680
(C Shape), 9.4mm
(C Shape), 8mm
connectors
