APPENDIX
APPENDIX >
Info
BQF (BUSINESS QUALIFICATION FORMULAR)
a
/2
17
* Function n° Way
2/2 NO
2/2 NC
3/2 NO
3/2 NC
* Function
direct
servo
membrane separate flow
* Actuation
monostable bistable
proportional
* Orifice size (mm)
1>2
2>3
* Connection Ports body/base
m5
1/8
1/4
other
flange
* Flow rate
1>2
2>3
Flow Factor (Kv)
* Pressure range (bar)
min
max
working pressure
back pressure
* Ambient temperature (°C)
min
max
* Media temperature (°C)
min
max
* Media
Water Hammer
no
yes
* Body material
* Seal material
static
dynamic
* Valve assembling
single
manifold
Coil assembling
0°
180°
* Manual override
bistable
monostable
no
* Electrical connection
(ex. Cable, pins, PCB etc)
Response time (msec)
on/off
off/on
* Coil voltage (Volt)
12
24
48
110
220
others
DC
AC
Power consumption (Watt/VA)
Protection degree IP
Frequency (Hz)
* Appruvals
* = mandatory data
NOTE:
ACCOUNT
SALES REP
BQF
