APPENDIX
APPENDIX >
Info
K8
K8B
K8DV
K 2/2
K 3/2
KN
KN High Flow W
VALVE
WIDTH
8mm
8mm
8mm
10mm
10mm
10mm
10mm
15mm
FUNCTION
2/2 - 3/2
NC - NO
2/2 -3/2
NC - NO
2/2
NC
2/2
NC
3/2
NC - NO
3/2
NC
3/2
NC
3/2
NC - NO
OPERATION poppet
spool
membrane
poppet
poppet
poppet
poppet
poppet
PNEUMATIC
CONNECTIONS cartridge
cartridge
cartridge
flange
flange
flange
flange
flange
flange
NOMINAL
DIAMETER
0.5mm
3.6mm
0.7mm
0.6 - 1 - 1.4mm 0.65mm
0.65mm
1.1mm
0.8 ... 1.5mm
FLOW
5 l/min
180 Nl/min
0.1 Kv (l/min)
0.18 … 45 Kv
10 l/min
10 l/min
25 l/min
14 … 35 l/min
OPERATING
PRESSURE 1 ÷ 7 bar
1 ÷ 7 bar
0 ÷ 2 bar
(low vacuum)
0 ÷ 2; 0 ÷ 3;
0 ÷ 6 bar
0 ÷ 5 … 7 bar
0 ÷ 7 bar
0 ÷ 3 … 7 bar
0 ÷ 5 … 10 bar
OPERATING
TEMPERATURE 0° ÷ +50°C
0° ÷ 50°C
0° ÷ 50°C
0° ÷ 50°C
0° ÷ +50°C
0° ÷ +50°C
0° ÷ +50°C
0° ÷ +50°C
MEDIA
inert gases
inert gases
aggressive gases
and liquids
inert gases,
oxygen
inert gases
inert gases
and liquids
inert gases
inert gas
SEALS
FKM
FKM
EPDM
FKM
FFKM
FKM
NBR
HNBR
NBR
NBR
FKM
PU
NBR
VOLTAGE
6 - 12- 24 V DC 6 - 12- 24 V DC 3 - 5 - 6 - 12 -
24 V DC
6 - 12- 24 V DC 6 - 12 - 24 V DC 24 V DC
24 V DC
24 - 48 V DC
POWER
CONSUMPTION 0.6 W
0.6 W
0.6 W
1 W
0.9 W
1.3/0.25 W 4/1 W
1 ... 2 W
DUTY CYCLE ED 100%
ED 100%
ED 100%
ED 100%
ED 100%
ED 100%
ED 100%
ED 100%
ELECTRICAL
CONNECTION
2 Pin 0.5 x 0.5
spacing 4mm
2 Pin 0.5 x 0.5
spacing 4mm
2 Pin 0.5 x 0.5
spacing 4mm
connector
cabels
connector - thin
cabels L = 300mm Connector
Connector
DIN 43650
(C Shape), 8mm
connector
C_FLUID CONTROL RANGE OF PRODUCTS
a
/2
13
When choosing a valve, it is essential to consider parameters linked to the mechanics of the product and to the environmental conditions of use. The Camozzi
range includes many solutions suitable to control different types of fluids with good performances and a high reliability, optimizing consumption and dimensions.
The table on the next page shows the main parameters to evaluate in order to find the most suitable type of valve.
Furthermore it is possible to develop customized solutions in order to satisfy the needs of every single client.
