C_FLUID CONTROL >
TECHNOLOGIES
Precision, repeatability and sensitivity
are the main characteristics being
pursued by our technical teams
involved in the development of
Series K8P and LRP (for pressure
control) and Series AP and LRW
(for flow control). Besides the vast
scientific applications, the need
for instruments to control microflow
and the use of components at very
low power has allowed us to study
new technologies that offer
“Energy-saving Piezo-solutions”.
PROPORTIONAL TECHNOLOGY
Main characteristics:
• High flow performance
• High insertion speed
• Resistant to aggressive fluids
• Self-cleaning
• A life of more than 50 million cycles
• Low void volume
• High precision and repeatability
• Sensitivity in the control of low flows
• Flow performance: from 0.5 l/min to 250 l/min
• Operating pressure: vacuum - 10 bar
• Connections: M5 - 1/8 - 1/4
• Nominal diameter: from 0.2mm to 6.5mm
• Materials in contact with the fluid:
PPS, Delrin, AISI 303 and 430, Brass,
Polyamide, Kalrez, FKM
• Operating temperatures: -10°C to +120°C
Camozzi develops solutions
for the control of fluids,
like solenoid valves with
a separating membrane (MSF).
In clinical diagnostics, where
reliability is key, solenoid valves
with a separating membrane
are used in the analysis
of blood, serum and urine
and in the handling of samples
and reagents as well as
the washing and treatment
of waste material. In analytical
chemistry, the analysis
of elements is the basis
for the research of materials.
The MSF solenoid valves and
the micro pumps represent
the core of instruments dedicated
to environmental monitoring,
water analysis and food quality
control.
Main characteristics:
• High flow performance
• High insertion speed
• Resistant to aggressive fluids
• Self-cleaning
• A life of more than 20 million cycles
• Low void volume
• High precision and repeatability
• Sensitivity in the control of low flows
• Fluids: biological and aggressive
liquids and gases
• Flow performance: from 0.5 l/min
to 5000 l/min
• Operating pressure: vacuum - 20 bar
• Connections: flange - M5, from 1/8 to 2”
• Nominal diameter: from 0.2mm to 50mm
• Materials in contact with the fluid:
PPS, Delrin, AISI 316, brass, aluminium,
Peek, Polyamide 6/6, Kalrez, Polyurethane,
FKM, NBR
• Operating temperatures: -10°C to +120°C
MEDIA ISOLATION AND GENERAL PURPOSE
