Series K8 solenoid valves C_FLUID CONTROL CATALOGUE
2
14
> 2018 CONTROL >
CONTROL
Single body for Series K8 solenoid valve
Material: anodized aluminium
Pneumatic connections: M5 threads
NOTE: to be used only with the
electrical connector Mod. 120-J...
Mod.
K8303/14C
Connector Mod. 120-..
Cable section: 0.25 mm²
Cable external diameter: 1.2 mm
Material for the cable insulation: PVC
Mod. description colour L = cable length (mm) cable holding
120-803 crimped cable white 300 crimping
120-806 crimped cable white 600 crimping
Connector with flying leads Mod. 120-J...
Flying leads section: 0.25 mm²
Flying lead external diameter: 1.2 mm
Material for the flying leads insulation: PVC
Mod. description colour L = cable length (mm) cable holding
120-J803 crimped cable connector J white 300 crimping
120-J806 crimped cable connector J white 600 crimping
