Kompaktzylinder Serie 32 Tandem- und Mehrstellungsversion
ANTREIBEN >
KATALOG
>
Version 8.8
/1.31.03
1
ANTREIBEN
Kompaktzylinder Mod: 32F2A/32M2A...N2 (Tandemversion)
Anbauteile/Zubehör siehe ab Seite 1/1.30 10.
PRODUKTÜBERSICHT
Ø A AF BG ØD ØD2 ØD3 ØD4 E EE E1 H H1 H2 KF
KK LA PL RT SW1 T1 T2 TG
25 16 11 16,5 10 -
-
9 40,7 M5
-
76 81,7 44 M6 M8X1,25 5 7 M5 8 -
2,5 26
40 19 13 21,5 12 35 29
9
57 G1/8 -
86 93 48,2 M8 M10X1,25 5 7,6 M6 10 2 2,5 38
63 22 16 18,5 16 45 39 12 79,6 G1/8 12’5 93 101
-
M10 M12X1,25 6 7,6 M8 13 2 3 56,5
100 28 20 20 25 55 49 12 115,6 G1/8 25 121 130,7 -
M12 M16X1,5 6 8 M10 22 2 3 89
+ Hub
++ 2x Hub
1 = Befestigungsnut für Sensor
2 = Ausfahrbewegung Zylinder
3 = Einfahrbewegung Zylinder
