Solenoids Mod. GP...
Electrical connection: bipolar
Norm: industrial standard (9.4 mm)
Solenoid material: PA
Mod. Solenoid voltage Power absorption
GPH 12 V DC 3 W
GP7 24 V DC 3 W
Solenoids Mod. B7...
Electrical connection: bipolar plus earth
Norm: DIN EN 175 301-803-B
Solenoid material: PA-MXD6
Mod. Solenoid voltage Power absorption
B7B 24 V - 50/60 Hz 9 VA
B7D 110 V - 50/60 Hz 9 VA
B7E 230 V - 50/60 Hz 9 VA
B7H 24 V - 50/60 Hz 4 VA
B72 12 V - DC 10 W
B73 24 V - DC 10 W
B74 24 V - DC 7 W
Solenoids Mod. G93 (with memory)
Electrical connection: bipolar plus earth
Norm: DIN EN 175 301-803-B
Voltage tolerance: ±10%
Pulsed operation (see description)
Mod. Voltage Minimum inpulse latch/release Consumption latch/release
G93 24 V DC 18 ms - 10 ms 168 mA - 80 mA
