Series AP proportional valves - size 22mm, with lower flanges
Mod.
Func. Orifice Ø (mm) kv (l/min) Max pressure (bar) Max flow (Nl/min)
AP-7215-FR2-U7*
2/2 NC
1
0.5
10
75
AP-7215-HR2-U7*
2/2 NC 1.2
0.7
8
85
AP-7215-LR2-U7*
2/2 NC 1.6
1.2
6
110
AP-7215-NR2-U7*
2/2 NC
2
1.7
5
135
AP-7215-QR2-U7*
2/2 NC 2.4
1.7
4
113
AP-7215-FW2-U7*OX2 2/2 NC
1
0.5
10
75
AP-7215-HW2-U7*OX2 2/2 NC 1.2
0.7
8
85
AP-7215-LW2-U7*OX2 2/2 NC 1.6
1.2
6
110
AP-7215-NW2-U7*OX2 2/2 NC
2
1.7
5
135
AP-7215-QW2-U7*OX2 2/2 NC 2.4
1.7
4
113
For the use with vacuum connect the line to
connection 2.
* choose the desired voltage
New
Series AP proportional valves, size 16mm - body in PVDF
Mod.
Port 1 Port 2 Function Orifice Ø
(mm)
kv (l/
min)
Max pressure
(bar)
Max flow
(Nl/min)
AP-621L-DR3-GP*
Ø6 ** Ø6 ** 2/2 NC 0.8
0.3
10
43
AP-621L-FR3-GP*
Ø6 ** Ø6 ** 2/2 NC 1
0.45
8
53
AP-621L-HR3-GP*
Ø6 ** Ø6 ** 2/2 NC 1.2
0.57
6
53
AP-621L-LR3-GP*
Ø6 ** Ø6 ** 2/2 NC 1.6
0.78
4
52
AP-621L-DW3-U7*OX2 Ø6 ** Ø6 ** 2/2 NC 0.8
0.3
10
43
AP-621L-FW3-U7*OX2 Ø6 ** Ø6 ** 2/2 NC 1
0.45
8
53
AP-621L-HW3-U7*OX2 Ø6 ** Ø6 ** 2/2 NC 1.2
0.57
6
53
AP-621L-LW3-U7*OX2 Ø6 ** Ø6 ** 2/2 NC 1.6
0.78
4
52
For the use with vacuum connect the line to
connection 2.
* choose the desired voltage
** pneumatic connection with
tube and clamps
