Connectors Mod. 122-800 DIN 43650
For size 22 mm only
Mod. 122-800EX:
for ATEX certified solenoids Mod. U7*EX,
with anti-screwing off screw Mod. TORX.
Mod. description colour working voltage cable holding tightening torque
122-800 connector, without electronics black - PG9 0.5 Nm
122-800EX connector, without electronics black - PG9 0.5 Nm
Connectors Mod. 122-550 DIN 43650 with cable
For size 22 mm only
Mod. description colour working
voltage
cable length
[ L ]
cable
holding
tightening
torque
122-550-1 moulded cable, without
electronics
black - 1000 mm - 0.5 Nm
122-550-5 moulded cable, without
electronics
black - 5000 mm - 0.5 Nm
Connector Mod. 124-800 DIN 43650
Protection class IP65
Mod. description colour working voltage cable holding tightening torque
124-800 connector, without electronics black - PG9/PG11 0.5 Nm
