Series PL solenoid valves CONTROL > C_FLUID CONTROL CATALOGUE > 2018
53
CONTROL
Industrial standard (9.4 mm) connector Mod. 125-...
Mod. description colour working voltage cable holding tightening torque
125-601 connector, diode + Led transparent 10/50 V DC PG7 0.3 Nm
125-701 connector, varistor + Led transparent 24 V AC/DC PG7 0.3 Nm
125-800 connector, without electronics black - PG7 0.3 Nm
1 = 90° adjustable connector
Industrial standard (9.4 mm) connector Mod. 125-... with cable
Mod. description colour working
voltage
cable length
[ L ]
cable
holding
tightening
torque
125-501-2 moulded cable with
diode + Led
black 10/50 V DC 2000 mm - 0.3 Nm
125-550-1 moulded cable, without
electronics
black - 1000 mm - 0.3 Nm
125-601-2 pre-wired cable, diode
+ Led
transparent 10/50 V DC 2000 mm PG7 0.3 Nm
125-571-3 moulded cable, varistor
+ Led
black 24 V AC/DC 3000 mm - 0.3 Nm
125-900 pre-wired cable with
voltage rectifier
black 6 V - 110 V
AC/DC
2000 mm PG7 0.3 Nm
The internal rectifier circuit of the connector
Mod. 125-900 allows to use solenoid valves with
different AC voltage, even if the voltage indicated on
the solenoid valve is DC.
1 = 90° adjustable connector
