Series PDV solenoid valves CONTROL > C_FLUID CONTROL CATALOGUE > 2018
71
CONTROL
Connector Mod. 126-... DIN EN 175 301-803-C (8 mm)
Mod. description colour working
voltage
cable length
[ L ]
cable
holding
tightening
torque
126-550-1 moulded cable,
without electronics
black - 1000 mm - 0.3 Nm
126-800 connector, without
electronics
black - - PG7 0.3 Nm
126-701 connector, varistor
+ Led
transparent 24 V AC/
DC
- PG7 0.3 Nm 1 = 90° adjustable connector
Industrial standard (9.4 mm) in-line connectors with cable
Mod. description colour working
voltage
cable length
[ L ]
cable
holding
tightening
torque
125-503-2 in-line moulded cable,
with diode + Led
black 24 V DC 2000 mm - 0.3 Nm
125-503-5 in-line moulded cable,
with diode + Led
black 24 V DC 5000 mm - 0.3 Nm
125-553-2 in-line moulded cable,
without electronics
black - 2000 mm - 0.3 Nm
125-553-5 in-line moulded cable,
without electronics
black - 5000 mm - 0.3 Nm
Industrial standard (9.4 mm) in-line connectors with bridge rectifier
Mod. description colour working
voltage
cable length
[ L ]
cable
holding
tightening
torque
125-903-2 in-line moulded cable
with voltage rectifier
black 6 V - 230 V
AC/DC
2000 mm - 0.3 Nm
125-903-5 in-line moulded cable
with voltage rectifier
black 6 V - 230 V
AC/DC
5000 mm - 0.3 Nm
