3/2-way solenoid valve Mod. A43
The 3/2-way NC solenoid valve, with G1/8 ports, incorporates a rapid exhaust valve.
It is particularly suitable for operating small single-acting cylinders.
Mod. Ports Function Orifice Ø mm Qn (Nl/min)
A431-1C2-* G1/8 / M5 3/2 NC 1.5 50
* choose the most suitable
solenoid.
3/2-way solenoid valve Mod. A33
They are particularly suitable for the actuation of small single-acting cylinders and the operation of pneumatic
valves with very low operating pressures.
Mod. Inlet / outlet Function Orifice Ø (mm) Man. override bistable Qn (Nl/min) Symbol
A331-3C2-* M5 / R1/8 3/2 NC 1,5 no 55 EV03
A331-4C2-* M5 / R1/8 3/2 NC 1,5 yes 55 EV08
The body has an outlet with
a R1/8 male thread which
can be screwed directly
onto the component to be
operated. The inlet port is
M5 threaded.
* choose the most suitable
solenoid.
