ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
81
Swivel ball joint Mod. GA
ISO 8139.
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
ØCN
U
EN
ER
AX
CE
KK
ØT
Z
SW
GA-160-200
160-200
35
28
43
40
56
125
M36x2
46
6
50
Clevis pin Mod. S
Supplied with:
1
x clevis pin (stainless steel 303)
2
x C-clips (plain carbon steel)
DIMENSIONS (mm)
Mod.
Ø
d
L
L1
L2
L3
S-160-200
160-200
30
179
170
1,6
4,25
Piston rod nut Mod. U
UNI EN ISO 4035.
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
D
m
SW
U-160-200
160-200
M36x2
14
55
