NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
80
Swivel combination Mod. I (combination of C + L + S)
DIMENSIONS (mm)
Mod.
Ø
ØCD
L
FL
D+
XD+
TG
E
ØN
I
I-41-160
160
30
35
55
180
315
140
175
17
20
I-41-200
200
30
35
60
180
335
175
215
17
25
+ = add the stroke
Counter bracket for centre trunnion Mod. BF
Material: Aluminium.
Supplied with:
2
x supports
DIMENSIONS (mm)
Mod.
Ø
ØCR
NH
C
B3
TH
UL
FK
FN
B1
ØB2
ØHB
BF-160-200
160-200
32
35
17,5
4
60
92
30
60
16
26
18
Rod fork end Mod. G
ISO 8140.
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
ØCK
LE
CM
CL
ER
CE
KK
B
ØB1
G-160-200
160-200
35
72
35
70
44
144
M36X2
92
60
EXPRESS DELIVERY AVAILABLE
