ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
72
Swivel ball joint Mod. GA
ISO 8139.
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
ØCN
U
EN
ER
AX
CE
KK
ØT
Z
SW
GA-160-200
160-200
35
28
43
40
56
125
M36x2
46
6
50
GA-250
250
40
33
49
-
60
142
M42x2
55
-
-
GA-320
320
50
45
60
58,5
65
160
M48x2
65
12
65
Clevis pin Mod. S
Supplied with:
1
x clevis pin (stainless steel 303)
2
x C-clips (plain carbon steel)
DIMENSIONS (mm)
Mod.
Ø
d
L
L1
L2
L3
S-160-200
160-200
30
179
170,5
1,6
4,25
S-250
250
40
210
202
-
4
S-320
320
45
236
222
1,85
7
Piston rod nut Mod. U
ISO 4035.
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
D
m
SW
U-160-200
160-200
M36x2
14
55
U-250
250
M42x2
16
65
U-320
320
M48x2
24
75
