COMPACT AND SHORT-STROKE CYLINDERS
107
COMPACT MAGNETIC CYLINDERS SERIES 31
Swivel ball joint Mod. GA
for cyl. 31M
90
° swivel combination
for trunnion Mod. I
Rear trunnion Mod. C Rod fork end Mod. G
for cyl. 31M
Piston rod nut Mod. U
for cyl. 31M
90
° swivel combin. for
fem. trunnion Mod. ZC
Rear trunnion Mod. L
Rear and front flange
Mod. D
All accessories are supplied separately.
Foot mount Mod. B
Coupling piece
Mod. GKF
Self aligning rod
Mod. GK
Piston rod socket joint
Mod. GY for cyl. 31M
