COMPACT AND SHORT-STROKE CYLINDERS
Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
106
CODING EXAMPLE
STANDARD STROKE FOR COMPACT MAGNETIC CYLINDERS SERIES 31
31
M 2
A
032
A
050
31
SERIES
31
= compact magnetic
M
VERSION
M = male rod thread
F = female rod thread
R = non-rotating with flange only double-acting
2
OPERATION
1
= single-acting front spring
2
= double-acting
3
= double-acting through-rod
4
= single-acting rear spring
A
MATERIALS
A = rolled stainless steel AISI 303 rod tube profile aluminum
032
BORE
012
= 12 mm
016
= 16 mm
020
= 20 mm
025
= 25 mm
032
= 32 mm
040
= 40 mm
050
= 50 mm
063
= 63 mm
080
= 80 mm
100
= 100 mm
A
DESIGN TYPE
A = standard
050
STROKE
(
see table)
= standard
S = special
V = rod seal FKM
W = seals in FKM for high temperatures (140°C)
● = Single-acting female, male ■= Double-acting female, male ✖ = Non-rotating
STANDARD STROKES
Ø
5
10
15
20
25
30
40
50
60
80
12
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
■ ✖
■ ✖
16
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
20
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
25
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
32
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
40
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
■ ✖
■ ✖
50
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
■ ✖
■ ✖
63
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
■ ✖
■ ✖
80
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
■ ✖
■ ✖
100
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖ ●
■ ✖
■ ✖
■ ✖
■ ✖
■ ✖
