Series T pressure microregulators
TREATMENT >
C_FLUID CONTROL CATALOGUE
>
2018
185
TREATMENT
Series T pressure microregulators
Ports G1/8 and G1/4
Series T pressure regulators are
available with G1/8 and G1/4 brass
connections.
A self-relieving piston has been
incorporated into the design to allow
decreasing adjustments.
Non-relieving versions are also available.
All models are equipped with a valve
enabling fast draining (VS) which is
useful when a regulator should be
inserted between the valve and cylinder
(or capacity) without any negative
influence on the exhaust.
»
»
Extremely lightweight
»
»
Compact
»
»
In-line or console mounting
GENERAL DATA
Construction
piston
Materials
technopolymer body and piston, stainless steel spring, brass inserts, NBR O-ring and poppet
Ports
G1/8 - G1/4
Weight
g 95
Pressure gauge ports
G1/8
Mounting
in-line or panel mounting (in any position)
Operating temperature
-5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature)
Inlet pressure
0 ÷ 12 bar
Outlet pressure
0, 5 ÷ 10 bar
Nominal flow
see graphs
Secondary pressure relieving standard
Type of fluid
air and water. Special versions for other types of gas are available upon request.
