General terms and conditions for sale are available on

www.camozzi.com.

3

Series N filter-regulators

TREATMENT >

C_FLUID CONTROL CATALOGUE

>

2018

TREATMENT

Flow diagrams for models: N204-D00 - N104-D00

Pa = Inlet pressure

Pr = Regulated pressure

Qn = Flow

Flow diagrams for models: N208-D00 - N108-D00

Pa = Inlet pressure

Pr = Regulated pressure

Qn = Flow

FLOW DIAGRAMS

1

8

9
