www.camozzi.com.Series N filter-regulators
C_FLUID CONTROL CATALOGUE
3
>
2018
TREATMENT >
TREATMENT
CODING EXAMPLE
N
SERIES
2
SIZE:
1 = small bowl (11 cm³)
2 = normal bowl (28 cm³)
04
PORTS:
08 = G1/8
04= G1/4
D
D = FILTER-REGULATOR
0
FILTERING ELEMENT:
0 = 25μm (standard)
1 = 5μm
0
DRAINING OF CONDENSATE AND DESIGN TYPE:
0 = semi-automatic manual drain with self-relieving
1 = semi-automatic manual drain without relieving
4 = depressurisation with self-relieving (with normal bowl only)
5 = protected depressurisation with self-relieving (with normal bowl only)
8 = no drain (direct port 1/8), with self-relieving
4
OPERATING PRESSURE:
= 0.5 ÷ 10 bar (standard)
2 = 0 ÷ 2 bar
4 = 0 ÷ 4 bar
7 = 0.5 ÷ 7 bar
BOWL MATERIAL:
= transparent PA12 (standard)
TM = nickel-plated brass (only in the small size with semi-automatic manual drain or without drain)
N 2 04
-
D 0 0
-
4
-
Mod.
A
B
C D
F
G I
L
M N
O
P
Q R
S
U
N108-D00
167
78
50
39
101
27
28
М30x1,5
45
45
G1/8
38
40
3
0 ÷ 6
G1/8
N104-D00
167
78
50
39
101
27
28
М30x1,5
45
45
G1/8
38
40
3
0 ÷ 6
G1/4
N208-D00
191
102
50
39
125
27
28
М30x1,5
45
45
G1/8
38
40
3
0 ÷ 6
G1/8
N204-D00
191
102
50
39
125
27
28
М30x1,5
45
45
G1/8
38
40
3
0 ÷ 6
G1/4
Series N filter-regulators
FR01 = filter-regulator with relieving and manual drain
FR02 = FR with relieving and without drain
FR11 = FR with manual drain and wiithout relieving
1
8
8
