Series M pressure microregulators
TREATMENT >
C_FLUID CONTROL CATALOGUE
>
2018
183
TREATMENT
Series M pressure microregulators
for use with water and fluids
Ports G1/8, G1/4
Series M pressure regulator is available
with G1/8 and G1/4 ports.
The versions with non nickel-plated body
are equipped with KTW certified seals
and can be thus used with water or non
aggressive fluids.
»
»
Versions with certified
diaphragms and seals
materials available
»
»
Version with non nickel-
plated body for applications
with water or fluids (gaseous
or liquid) available
GENERAL DATA
Construction
diaphragm type
Materials
body: non nickel-plated brass
spring: stainless steel
seals: diaphragm in EPDM (H versions only)
Ports
G1/8 - G1/4
Weight
Kg 0.235
Pressure gauge ports G1/8
Mounting
in-line or panel mounting (in any position)
Operating temperature 10°C ÷ 50°C with water
Inlet pressure
0 ÷ 16 bar
Outlet pressure
0.5 ÷ 10 bar
Nominal flow
air: Qn 480 (Nl/min)
water: Kv 0.42 (N3h)
