CONTROL > Series EN
Manifolds for valves size 16 and 19
(outlets on the body valve)
Mod. EN531-1002
EN531-1003
EN531-1004
EN531-1005
EN531-1006
EN531-1008
EN531-1010
EN531-1012
EN551-1002
EN551-1003
EN551-1004
EN551-1005
EN551-1006
EN551-1008
EN551-1010
EN551-1012
Manifolds for valves size 16 and 19
(outlets on manifolds)
Mod. EN530-2102
EN530-2103
EN530-2104
EN530-2105
EN530-2106
EN530-2108
EN530-2110
EN530-2112
EN550-2102
EN550-2103
EN550-2104
EN550-2105
EN550-2106
EN550-2108
EN550-2110
EN550-2112
Accessories
Manifolds
Blanking plate for manifolds - valves
with outlets on the body
The following is supplied:
1x blanking plate,
2x screws,
1x seal
Mod. TP-EN531
TP-EN551
Blanking plate for manifolds - base
mounted valves
The following is supplied:
1x blanking plate,
2x screws,
1x seal
Mod. TP-EN530
TP-EN550
Mounting brackets for DIN rail
DIN EN 50022 (7,5 mm x 35 mm - width 1)
Suitable for all manifolds.
Supplied with:
2x plates,
2x screws M4x6 UNI 5931
2x nuts
Mod. PCF-EN531
Connectors DIN 43650, pin spacing 9,4 mm
Mod. 125-601
125-701
125-800
In-line connectors with moulded cable
Mod. 125-503-2 (cable 2000 mm)
125-503-5 (cable 5000 mm)
125-553-2 (cable 2000 mm)
125-553-5 (cable 5000 mm)
In-line connectors with moulded cable
and bridge rectifier
Mod. 125-903-2 (cable 2000 mm)
125-903-5 (cable 5000 mm)
Connectors DIN 43650,
pin spacing 9,4 mm with cable
The internal rectifier circuit of the connector
Mod. 125-900 allows to use solenoid valves
with different AC voltage, even if the voltage
indicated on the solenoid valve is DC
Mod.125-501-2 (cable 2000 mm)
125-550-1 (cable 1000 mm)
125-601-2 (cable 2000 mm)
125-571-3 (cable 3000 mm)
125-900 (cable 2000 mm)
Connectors DIN 43650 pin spacing 8 mm
To be used in all DC valves with voltages
from 6 to 110 V
Mod. 126-550-1 (cable 1000 mm)
126-800
126-701
