ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
70
Rear male trunnion Mod. L
Material: Aluminium.
Supplied with:
1
x male trunnion
4
x screws
DIMENSIONS (mm)
Mod.
Ø
ØCD
L
FL
XD+
MR
E
EW
L-41-160
160
30
35
55
315
30
175
90
L-41-200
200
30
35
60
335
30
215
90
L-41-250
250
40
45
70
375
40
270
110
L-41-320
320
40
50
80
375
45
270
110
+ = add the stroke
Centre trunnion Mod. F
Material: white zinc-plated steel.
Supplied with:
1
x centre trunnion
4
x clamping elements
8
x locking screws
DIMENSIONS (mm)
Mod.
Ø
XV 1
XV + 1/2
XV3 +
TM
TK
ØTD
TL
UW
R
F-160
160
145
170
195
200
40
32
32
200
0,2
F-200
200
160
185
210
250
40
32
32
250
0,2
F-250
250
185
205
225
320
50
40
40
300
-
F-320
320
210,5
230
249,5
400
70
50
50
400
-
+ = add the stroke
90
° Swivel combination Mod. ZS*
Material: Aluminium.
*
not according to standard
Supplied with:
1
x 45° swivel combination
DIMENSIONS (mm)
Mod.
Ø
TR
ØAB
AH
C
G
ØCD
XD +
G3
ZS-160
160
140
18
140
20
180
30
315
105
ZS-200
200
175
18
140
25
220
30
335
125
+ = add the stroke
