NORTH AMERICAN CYLINDER & ACTUATOR CATALOG - page 28

NORTH AMERICAN CYLINDER & ACTUATOR CATALOG > Release 8.5
The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
ISO / VDMA CYLINDERS
ISO / VDMA Cylinders 1
5
CODING EXAMPLE
STANDARD STROKES FOR MINICYLINDERS SERIES 16 - 24 and 25
24 N 2 A 16 A 100
24 SERIES:
16 = non-magnetic piston (bore sizes 8, 10 or 12 only)
24 = magnetic piston (bore sizes 16, 20 or 25 only)
25 = magnetic piston and adjustable cushions (bore sizes 16, 20 or 25 only)
N VERSION
N = standard
2 OPERATION
1 = single-acting (front spring)
2 = double-acting
3 = double-acting (through-rod)
7 = single-acting (through-rod)
A MATERIALS
rod = rolled stainless steel AISI 303
tube = stainless steel AISI 304
end-caps = anodized AL
16 BORE:
08 = 8 mm
10 = 10 mm
12 = 12 mm
16 = 16 mm
20 = 20 mm
25 = 25 mm
A CONSTRUCTION
A = threaded nose mount with lock nut + lock nut for rod
RL = cylinder with rod lock ø20 - ø25 (rod extension required. See table.)
100 STROKE
(see table)
= standard
V = rod seals FKM (VITON)
■ = Double-acting
✖ = Single-acting
STANDARD STROKES
Series Ø 10 25 40 50 80 100 125 160 200 250 300 320 400 500
16 8 ■✖ ■✖ ■✖ ■✖ ■ ■ ■ ■ ■
16 10 ■✖ ■✖ ■✖ ■✖ ■ ■ ■ ■ ■
16 12 ■✖ ■✖ ■✖ ■✖ ■ ■ ■ ■ ■ ■ ■
24 16 ■✖ ■✖ ■✖ ■✖ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
24 20 ■✖ ■✖ ■✖ ■✖ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
24 25 ■✖ ■✖ ■✖ ■✖ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
25 16 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
25 20 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
25 25 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
MAXIMUM STROKE LENGTHS (mm)
Series (and Ø) Min-Max Stroke (Produced in USA) Min-Max Stroke (Produced in Italy)
16 (Ø 8-10) 10-250 mm 10-250 mm
16 ( Ø 12) 10-300 mm 10-300 mm
24, 25 ( Ø 16) 10-600 mm 10-600 mm
24, 25 (Ø 20-25) 10-600 mm 10-1000 mm
EXPRESS DELIVERY AVAILABLE
