ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
9
Foot mount Mod. B
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
TR
US
ØAB
C
NH
AO
AU
RX
XA+
SA+
XS
Weight (g)
B-8-10
8-10
25
35
4,5
2,5
16
4,5
10,5
10
72,5
67
54
46
B-12-16
12
32
42
5,5
3
20
6
13
13
82,5
71
64
78
B-12-16
16
32
42
5,5
3
20
6
13
13
91
82
68
78
B-20-25
20
40
54
6,6
4
25
8
16
20
108
100
80
174
B-20-25
25
40
54
6,6
4
25
8
16
20
113,5
101,5
85,5
174
Supplied with:
2
x feet
1
x front end cap nut
mod. V
+ = add the stroke
Front/rear flange mount Mod. E
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
C
ØFB
TF
UF
UR
W
ZF
Weight (g)
E-8-10
8-10
2,5
4,5
30
25
40
13,5
64,5
10
E-12-16
12
3
5,5
40
30
53
19
75
21
E-12-16
16
3
5,5
40
30
53
19
81
21
E-20-25
20
4
6,6
50
40
66
20
96
39
E-20-25
25
4
6,6
50
40
66
24
101,5
39
+ = add the stroke
