ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
12
Self aligning rod Mod. GK
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
KK
L
L1 L3 L4 ØA ØD H I
SW SW1 SW2 B1 AX Z E Weight (g)
GK-20
20
M8x1,25
57
26 21
5
8 12,5 19 17 11
7
13
4
16 4 2
51,5
GK-25-32
25-32
M10x1,25 71,5 35 20 7,5 14
22
32 30 19
12
17
5
22 4 2
215
Coupling piece Mod. GKF
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
KK
A
B
R TF
L
L1
I
Ø D Ø D1
Ø D2
SW E
Weight (g)
GKF-20
20
M8x1,25
30
35
20
25
22,5
10
-
14
5,5
-
13
1,5
76
GKF-25-32
25
M10x1,25
37
60
23
36
22,5
15
6,8
18
11
6,6
15
2
240
