ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
11
Piston rod socket joint Mod. GY
ISO 8139
Material: Zinc-Aluminum alloy and
zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
KK
L
CE L2 AX E ØB ØC ØT ØD L1
L3 SW1 SW Z Weight (g)
GY-12-16
12-16
M6X1
40 28
5
15
6
10 20
10
13 12,2 11
8
11
15
42
GY-20
20
M8X1,25
65 32
5
16
8
12 24 12,5 16
16
12
10
14
15
74
GY-32
25
M10X1,25 74 35 6,5 18 10 14 28
15
19 19,5 15
11
17
15
122
Piston rod nut Mod. U
UNI EN ISO 4035
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
D
m
SW
Weight (g)
U-8-10
8-10
M4X0,7
3
7
0,5
U-12-16
12-16
M6X1
4
10
1,6
U-20
20
M8X1,25
5
13
3,6
U-25-32
25
M10X1,25
6
17
7,6
Front End-Cap nut Mod.V
UNI EN ISO 4035
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
D
m
SW
Weight (g)
V-8-10
8-10
M12X1,25
5
19
10,2
V-12-16
12-16
M16X1,5
6
24
15
V-20-25
20-25
M22X1,5
10
32
32
