Series 8 pneumatically and electropneumatically operated valves
CONTROL >
C_FLUID CONTROL CATALOGUE
>
2018
97
CONTROL
CODING EXAMPLE
8 10 C3 4 04 - F1 3 1 Y - N 00 2C C015
8
SERIES
10
SIZE:
10 = Size 1
20 = Size 2
30 = Size 3
C3
TYPE OF BODY:
C3 = threaded body
4
NUMBER OF WAYS - FUNCTIONS:
1 = 2/2-way NC
2 = 2/2-way NO
4 = 3/2-way NC
5 = 3/2-way NO
04
PNEUMATIC CONNECTIONS:
04 = G1/8 (Size 1)
05 = G1/4 (Size 2)
06 = G3/8 (Size 3)
F1
NOMINAL DIAMETER:
F1 = 5.0 mm (Size 1)
G7 = 6.6 mm (Size 2)
K1 = 9.0 mm (Size 3)
3
SEAL MATERIAL:
3 = FKM
1
BODY MATERIAL:
1 = aluminium
Y
MANUAL OVERRIDE:
N = not provided
Y = provided monostable
N
MOUNTING ACCESSORIES:
N = not provided
00
OPTIONS:
00 = no option
PP = pneumatic piloting
PE = electropilot with external piloting
2C
ELECTRICAL CONNECTION:
2C = connection type KN 90° + protection + led (Size 1)
2F = connection type KN 90° in line + protection + led (Size 1)
3A = connection DIN EN 175 301-803-C (8 mm)
4A = industry standard connection (9.4 mm)
7A = wires - length 300 mm (Size 2 - 3)
C015
VOLTAGE - POWER CONSUMPTION:
C012 = 12V DC 1.3/0.25W (Size 1)
C014 = 24V DC 1.3/0.25W (Size 1)
C020 = 12V DC 2W (Size 2 - 3)
C023 = 24V DC 2W (Size 2 - 3)
C025 = 48V DC 2W (Size 2 - 3)
VERSION:
= standard
OX1 = for use with oxygen (non volatile residual less than 550 mg/m²)
OX2 = for use with oxygen (non volatile residual less than 33 mg/m²)
