Series K8B solenoid valves

CONTROL >

C_FLUID CONTROL CATALOGUE

>

2018

17

CONTROL

8 mm solenoid valve, 2/2 and 3/2-way NC and NO

Mod.

Function

NOTE

K8BC5100-D432N-N001A*

2/2 NC

* enter the required voltage (see the coding example)

K8BC5200-D432N-N001A*

2/2 NO

* enter the required voltage (see the coding example)

K8BC5400-D432N-N001A*

3/2 NC

* enter the required voltage (see the coding example)

K8BC5500-D432N-N001A*

3/2 NO

* enter the required voltage (see the coding example)

8 mm solenoid valve seat, 2/2 and 3/2-way NC and NO

* = FOR THE 2/2 VERSION THIS OPERATION HAS NOT TO BE PERFORMED

** = TO ACHIEVE DECLARED PERFORMANCE IT IS NECESSARY TO HAVE

A PASSAGE SECTION FOR THE SUPPLY AND EXHAUST PORTS

OF 12.5 mm², WHICH IS EQUAL TO A Ø4 mm
