Series K8B solenoid valves
CONTROL >
C_FLUID CONTROL CATALOGUE
>
2018
19
CONTROL
Body for subbase, 2/2-way NC and NO
Supplied with:
1x connector with flying leads
Mod. 120-J803 (300mm)
2x interface seals
2x screws M3x6 UNI 5931
(for M version)
or
2x screws M3x6 UNI 10227
(for P version)
Mod.
Function
Symbol
NOTE
K8BC0118-D431N-*001B**
2/2 NC
EV49
* enter the type of screws - ** enter the required voltage (see the coding example)
K8BC0218-D431N-*001B**
2/2 NO
EV50
* enter the type of screws - ** enter the required voltage (see the coding example)
Body for subbase, 3/2-way NC and NO
Supplied with:
1x connector with flying leads
Mod. 120-J803 (300mm)
3x interface seals
2x screws M3x6 UNI 5931
(for M version)
or
2x screws M3x6 UNI 10227
(for P version)
Mod.
Function
Symbol
NOTE
K8BC0419-D431N-*001B**
3/2 NC
EV51
* enter the type of screws - ** enter the required voltage (see the coding example)
K8BC0519-D431N-*001B**
3/2 NO
EV52
* enter the type of screws - ** enter the required voltage (see the coding example)
