www.camozzi.com.Series VBO and VBU blocking valves
C_FLUID CONTROL CATALOGUE
2
170
>
2018
CONTROL >
CONTROL
Unidirectional blocking valve
DIMENSIONS
Mod.
A
B
C
F
H
L
M N SW
VBU 1/8 1/8
1/8
16,9
20
5,5
43
24,5
30
15
VBU 1/4 1/4
1/4
20,5
25
7
50
32,2
33,5
19
VBU 3/8 3/8
3/8
26,8
33
8
67
40
39,5
24
VBU 1/2 1/2
1/2
30
45,5
9
85,7
52
48
27
Bidirectional blocking valve
DIMENSIONS
Mod.
A
B
C
F
H
L
M N SW
VBO 1/8 1/8
1/8
16,9
20
5,5
43
24,5
30
15
VBO 1/4 1/4
1/4
20,5
25
7
50
32,2
33,5
19
VBO 3/8 3/8
3/8
26,8
33
8
67
40
39,5
24
VBO 1/2 1/2
1/2
30
45,5
9
85,7
52
48
27
